True TS-49F-4-HC, Commercial 54" Reach-In Freezer Solid Doors 2 Section

The True TS-49F-4-HC two-section reach-in freezer includes six shelves that have a wire design to provide airflow through small gaps, evenly cooling stored items. These shelves are PVC coated for corrosion resistance and can be adjusted to accommodate different items. Airflow guards are integrated into the cabinet, preventing users from placing items in the path of air flow and obstructing it. Since the interior is made of stainless steel, it simplifies cleaning and is durable to support heavy use. This two-section unit has four doors, With two doors in each section, the unit has four doors total, limiting access and retaining more cold air than models with full doors.

For frozen food and ice cream, this True TS-49F-4-HC reach-in freezer operates at -10 degrees Fahrenheit, a temperature that can be monitored on the digital exterior display. The unit uses R290 hydrocarbon refrigerant to Maintaining the correct temperature, the unit uses eco-friendly R290 refrigerant. Cold air is evenly moved through the cabinet with fans, which have efficient, electrically-commutated fans. Because the condensing unit is mounted in the bottom, it is accessible for maintenance, though this position means it can suck in floor dirt and debris. Defrost cycles are needed in freezers to remove buildup that comes from condensate water freezing, and in this unit, the defrost system is automatic, starting based on a timer and shutting off when the temperature is back to the right level.

Every time the compressor fan motor in this unit turns on, it blows in reverse for 20 seconds, reducing the collection of dust and dirt on the condensing coil. This mechanism helps with daily operation, improves system efficiency, and reduces energy consumption. It also ensures storage temperatures are as cold and consistent as possible. Overall, the reversing feature prolongs the lifespan of the unit, but it doesn't replace the need for routine preventative maintenance.

Product Details

• 6 PVC-coated wire shelves are adjustable in ¹⁄₂-in. increments
• Rear airflow guards prevent product from obstructing the flow of cold air
• LED interior lighting increases visibility in the cabinet
• Durable stainless steel interior simplifies cleaning
• 4 half doors self-close to retain cold air
• 12-in. recessed door handles
• 1-piece, magnetic door gaskets seal in cold air and are removable without tools
• Stainless steel exterior front, doors, and sides
• GalFan-coated steel back
• Foamed-in-place polyurethane insulation helps keep cold air in the cabinet
• 4-in. castors with locking front set

High-capacity Refrigeration System

• Operating temperature: -10 degrees F
• External digital temperature display
• R290 hydrocarbon refrigerant
• Evaporator and condenser fan motors are electronically commutated to reduce energy consumption and minimize heat production
• Reverse blowing fan motor eliminates buildup on condenser coil
• Epoxy coating on the evaporator provides corrosion resistance
• Condensing unit is bottom mounted and maintenance accessible
• Time-initiated, temperature-terminated automatic defrost

Dimensions & Utilities

• Shelves: 24⁹⁄₁₆ in. W x 22³⁄₈ in. D
• Overall: 54¹⁄₈ in. W x 29¹⁄₂ in. D x 83³⁄₈ in. H
• 9.6 A, 1 HP
• 115 V/60 Hz/1 ph, 9-ft. cord with a NEMA 5-15P plug

True Refrigeration TS-49F-4-HC Specifications
